Polyple is an interactive N-dimensional geometry editor for building, transforming, animating, and rendering high-dimensional objects through 3D projection.

• Orbit: left drag. Zoom: wheel.
• Reset rotations button: reset extra-axis rotations without stopping active auto-rotation.
• Perspective depth: use the depth button on an extra-axis gizmo to include/exclude that axis from perspective depth.
• XYZ gizmo: drag the gizmo to move/orbit the view, or tap an endpoint to snap the camera to that axis.
• Extra-axis gizmos: drag one of the plane dots to rotate the named plane for that hidden axis.
• Object origin: double click an object to focus the camera on its fixed origin. Use the object context menu to recalculate that origin from the current center of mass.
• Axis auto-rotate: use the tiny play button on a gizmo to cycle 1x, 2x, 3x, then stop for its selected plane. Press P to play/pause active extra-axis rotations.
• Axis swapping: drag the center of an extra-axis gizmo over an XYZ tip to swap it with that projected axis.
• Faceted mode: every object uses the same opaque multicolor material with one color per coplanar outer face region.
• Keyframes: right click the timeline or viewport to insert a keyframe or remove the last keyframe. The timeline shows the current frame and keyframe markers.
• Insert keyframe: press I at the current frame.
• Remove keyframe: press U to remove the last keyframe at or before the current frame.
• Animation playback: use the play button or Space to preview the keyframed animation.
• Render controls: use the bottom mode box for wireframe/rendered/faceted, the timeline buttons for previous/play/next, and the Render tab for FPS, frame count, capture, quality, and effects.
• Add object: Shift + A opens the primitive library.
• Transform selected object: G move, R rotate, S scale.
• Mobile transforms: tap Move/Rotate/Scale to toggle a mode, then drag the object gizmo handles to transform.
• Delete selected object: X.
• Edit mode: Tab. Use 1..8 or the small dimension buttons for vertex, edge, face, volume, and higher-cell selection, then G/R/S to transform the selected component. In face and higher-cell modes, click center dots for precision or repeated-click/Alt+click to cycle overlapping cells.
• Undo/Redo: Ctrl/Cmd + Z, Ctrl/Cmd + Y.
• Close this panel: close button, tap outside, or Esc.
